DX-CP27 Mini Ibeacon & Eddysotne

Chipset: Dialog14531Bluetooth 5.1

Size: 40 * 24 * 5 mmwaterproof：IP67

Distance: 90~100mBattery life: 1~2years

Usage: Small sports competitions, dangerous goods storage management, drug management, large-scale concerts ,etc

DX-CP29 Card Ibeacon & Eddysotne

Chipset: Dialog14531 Bluetooth 5.1Size: 53 * 85 * 6 mm

Charge：Supports Tyce-C chargingIntervals: 100ms~1000ms

Distance: 100~120mBattery life: 1~2years

Usage: Personnel positioning, SOS button, access control record, medical information tracking ,etc

DX-CP28 Ultra low power Beacon

Chipset: Dialog14531 Bluetooth 5.1Size: 61 * 61 * 18 mm

battery: 880mAh * 2（CR 2477）Intervals: 100ms~1000ms

Distance: 100~120mBattery life: 3~5years

Usage: Goods tracking, warehouse management, personnel positioning, information push, etc

DX - BT24-S Small size Bluetooth

Module size: 14.5×12mmChip scheme: DA14531

Transmission rate: 10KB/sBluetooth protocol: BLE5.1

Certification: CE FCC SRRC

Energy saving mode: Hibernation mode 2uA Low power mode 19uA

DX - BT24-T Supermini size

Module size: 8.3×7.6mmChip scheme: DA14531

Transmission rate: 10KB/sBluetooth protocol: BLE5.1

Antenna type: Ceramic & externalCertification: CE FCC

Energy saving mode: Hibernation mode 2uA Low power mode 19uA

DX - BT31 Big data Bluetooth

Module size: 26.7×13mmCommunication distance: 90M

Transmission rate BLE: 20KB/sTransmission rate SPP: 60KB/s

Bluetooth protocol: SPP5.0+BLE5.0Transmit power: 6dBm Max

Baud rate: 4800bps ~ 4000000bps

DX - BT04-E02

Module size: 26.6×12.8mmCommunication distance: 75M

Bluetooth protocol: SPP3.0+BLE4.2Transmission rate BLE: 4.8KB/s

Transmission rate SPP: 10KB/sAntenna type: Onboard & external

Certification: CE FCC

DX - BT27 Long distance bluetooth

Module size：26.6×12.8mmChip scheme：DA14531

Communication rate：10KB/sCommunication distance: master/slave 580M mobile phone 200M

Transmitting power：-8.5~+13.5dBmCertification: CE FCC

DX - BT04-E Classic Bluetooth SPP+BLE

Module size：15.8×11.4mmCommunication distance：75M

Bluetooth protocol：SPP3.0+BLE4.2Transmission rate SPP：10KB/s

Transmission rate BLE：4.8KB/sAntenna type：On-board antennas

authentication：CE FCC SRRC BQB

DX - BT24 Low -power Bluetooth

Module size：26.6×12.8mmChip solution：DA14531

Bluetooth protocol：BLE5.1Communication rate：10KB/s

Antenna type: onboard & externalCertification：CE FCC SRRC BQB IC

Energy saving mode: hibernation mode 2uA low power consumption mode 19uA
